Now Certified to the NEW NFPA 1970 Standard!
Elite Pro hoods are specifically designed to improve comfort and provide greater freedom of movement while significantly reducing tugging or pulling away from the SCBA facepiece. Tapered back, notched shoulder drape and patterned bib perfectly interface with turnout collars and SCBA strapping.
Particulate coverage throughout entire head including Sure‑Fit™ panel at crown and entire bib.
Quilted composite with PFAS-free durable water resistant finish on the exterior layer and a dual-technology antimicrobial and anti-odor finish on the inside layer with Nomex® Nano Flex between layers for excellent stretch, recovery and odor control. Highest air permeability of particulate fire hoods on the market at 23 cfm, approximately 3-6 times greater than PTFE laminated hoods. Averages 97.4% particulate efficiency for particulates between 0.1 and 1.0 microns. PGI quilted BarriAire composite fabrics recently achieved Viral Filtration Efficiency (VFE) Rating of 96.8% and Bacterial Filtration Efficiency (BFE) Rating of 97.9% (as conducted by Nelson Labs, U.S.A.). NFPA 70E Hazard Risk Category 4.
| Fabric Performance Values | Requirements NFPA 1970 2025 Edition |
PGI Test Results |
| Particulate Efficiency | ||
|
Quilted Composite |
||
|
≥ 90% | 97.4% |
|
≥ 90% | 97.3% |
|
Seam at Crown and Panels |
||
|
≥ 90% | 95.5% |
|
≥ 90% | 98.4% |
|
Seam at Drape Attachment |
||
|
≥ 90% | 95.7% |
|
≥ 90% | 97.5% |
| Viral & Bacterial Filtration Efficiency | ||
|
N/A | 96.8% |
|
N/A | 97.9% |
| Air Permeability (As Received) | N/A | 23 cfm |
| Thermal Protective Performance (TPP) | 20.0 (min) | 25.7 |
| Total Heat Loss (THL) | ≥ 325 W/m2 | 379.5 W/m2 |
| Hood Material Burst Strength | ≥ 225 N | 1352 N |
| Flame Resistance Test – Quilted Composite | ||
|
After Flame (Wales x Courses) |
||
|
≤ 2.0 sec | 0.3 sec x 0.7 sec |
|
≤ 2.0 sec | 1.3 sec x 1.0 sec |
|
Char Length (Wales x Courses) |
||
|
≤ 100 mm | 27 mm x 4 mm |
|
≤ 100 mm | 7 mm x 3 mm |
| Cleaning Shrinkage Resistance Test | ||
|
Hood Measurement |
||
|
≥ -5% | 0.7% |
|
Face Opening Measurement |
||
|
Meets Requirement | YES |
| Heat & Thermal Shrinkage Resistance Test | ||
|
Hood Measurement |
||
|
≥ -10% | -1.8% |
|
≥ -10% | -0.3% |
|
Face Opening Measurement |
||
|
Meets Requirement | YES |
|
Meets Requirement | YES |
| Limited Oxygen Index (LOI) | Not Required | 40 |
| Seam Breaking Strength Test | ||
|
≥ 181 N | 1389 N |
|
≥ 181 N | 1139 N |
| Melt or Drip When Exposed to Flame | No Melting or Dripping | NONE |
| Arc Thermal Performance Value (ATPV) | 46 cal/cm2 | |
| NFPA 70E Hazard Risk Category (HRC) | HRC 4 |
